Parameters

Every parameter you declare becomes a row on somebody's form. Orbital Control renders exactly what you declared, so the description you write is the only help they get.

A parameter is a named, typed blank in your tile that the person binding it fills in. You declare them in params on your space.highport.sites.tile record. Whoever binds the tile supplies values under the same names in their site record's parameters map. Your files read the resolved result at /_bard/params.json. The rest of this page is the detail of those three steps.

A tile may declare at most 32 parameters, and no two may share a name.

The declaration

Each entry of params is a space.highport.sites.tile#param. Four fields apply to every type. Everything else is a constraint, and each constraint belongs to one type only.

A parameter name may not begin with _. That prefix is reserved, because parameters are materialized under /_bard/params/.

A tile with three parameters: one required record, one optional string, one optional boolean.

"params": [
        { "name": "profile", "type": "app.bsky.actor.profile", "required": true,
          "description": "The profile record that is rendered" },
        { "name": "heading", "type": "string", "maxLength": 240, "maxGraphemes": 60,
          "description": "Shown above the profile. Defaults to the display name." },
        { "name": "showReplies", "type": "boolean",
          "description": "Show recent replies under the profile. Off by default." }
      ]


The types

Six kinds, and what each one means at both ends.

A parameter the site owner did not supply is absent from /_bard/params.json entirely. It is not null and not an empty string.

Blob parameters

This is the one that catches people. A blob parameter arrives in params.json as the blob reference the record carried, and a blob reference is not fetchable. Read params.json to learn whether the owner supplied a file. The bytes are a separate entry at /_bard/params/{name}{pointer}, where pointer is the RFC 6901 JSON Pointer to the blob inside the resolved value, and is empty when the parameter is the blob.

The declaration side needs nothing more. Building a tile has the paths and how to read them. On this page a blob is a type with two constraints, accept and maxSize.

Array parameters

An array must declare items, and items is a #itemSchema: a type plus the same constraint fields, with no name, required, description or nested items of its own. An array is one level deep and an item may never itself be an array.

Two item types have no working control on the site owner's form, so do not declare them: an array whose items.type is blob, and an array whose items.type is an NSID. The field renders, the owner fills something in, and the record is then refused with ParameterTypeMismatch. Declare a single blob or a single record parameter instead, or several of them.

Record parameters

Set type to the NSID of the record type you want, app.bsky.actor.profile for instance. The site owner picks one of their own records of that collection, or pastes an at:// URI and pins it, or types a record inline.

Whichever they choose, your tile receives the resolved record, not the reference. The reference itself is recorded separately, in /_bard/site.json's parameterSources, keyed by /{name}.

A record type accepts no constraint fields at all. Lexicon constrains a record with the schema it refers to, never with a maxLength.

Two things follow from the resolution being one level deep. Strong references inside a resolved record are not followed. And a blob inside a by-reference value is fetched from the referenced record's account, while a blob inside an inline value is fetched from the site owner's. Which is why copying somebody else's profile inline fails and pinning it by reference works.

Constraints

A constraint field is only legal on the type Lexicon defines it for. This table is the rule.

name, type, required and description are not constraints and are legal on everything, which is why they appear in no row.

enum beats everything else a string declares. A string with both enum and format: uri renders as a menu and not a URL box. There is nothing to type, so the format never comes up. knownValues is the reverse: it is tested after format, so format: uri plus knownValues renders a URL box and the suggestions are dropped.

A constraint on the wrong type is an error

It is not quietly ignored. maxLength on an integer makes your tile invalid, and an invalid tile cannot be bound by anybody. The message names the field and the type:

`params` entry "count": `maxLength` is not a constraint Lexicon defines for `integer`


The same holds for format. The set is closed against what Lexicon actually implements: the eleven the schema names, plus space-ref, which the builder does not offer and the form does not check. So format: "email" is refused on your tile, not on every site that tries to supply a value for it.

There are no defaults

You cannot declare a default value for a parameter, anywhere. That is deliberate, not missing.

Leave an optional parameter empty and it is left out entirely. Your description is the only place you get to say what your tile does when that happens, and your code must handle the absence:

const heading = params.heading ?? profile.displayName;
      const count = params.count ?? 10;


Descriptions are the help text

The site owner's form is generated from your params array, in declaration order, one control per parameter, with your description rendered as the help text under the label. You will not be in the room. Write it as though somebody is reading it, because they are.

A good description says what the value is for, where it appears, and what happens if it is left blank. A poor one restates the label.

Good:  Shown above the profile. Defaults to the display name.
      Poor:  The heading.


For a required parameter, say what it is for and what a reasonable value looks like. "The profile record that is rendered" is doing more work than "profile" is.

The form your declaration becomes

Each type maps to one control. A tile that declares nothing renders "This tile declares no parameters."

Declaring maxLength or maxGraphemes adds a character counter under the field. It shows one budget instead of two, whichever of the two is proportionally fuller, until the value goes over one of them. Then both appear.

A blob field says "No file chosen. At most {maxSize}." when you declared one, then "Uploading to your PDS…", then the type and size it stored. A record field says "Nothing pinned yet. Highport stores the URI and the CID it has right now." until they choose, then names the URI and the CID it pinned.

How a failure reaches the site owner

Two passes, and they see both.

As they type. Every constraint you declare becomes a check the form runs when they leave the field, carrying the error name the server would have used. MissingParameter for an empty required field, ParameterConstraintViolation for a broken bound, ParameterTypeMismatch for the wrong kind of value. So the sentence somebody reads while typing is the sentence they would have read after a round trip. Using a tile on your site lists what each one says. These are a courtesy, not the rule.

When they validate. space.highport.manage.validate is the authority, and it returns parameter faults in parameterErrors rather than errors. The site editor lists them under the heading "Fix these in your details above". They are not attached to individual fields, so a long form with one broken value takes some reading.

The message carries the validator's own wording, prefixed with the parameter name, which is why a site owner sees the limit expressed the way their PDS would express it:

parameters.count: must be ≤ 50


Every error a binding can produce

These are the names a site owner meets when their values do not match your declaration. Each is reported against parameters.{name} and, for a value nested inside a record or an array, the JSON Pointer to the exact spot.

A pass reports every fault it finds instead of stopping at the first. The first becomes the record's error name and the rest are appended as (and N more: …), so a record with four broken parameters is one publish cycle and not four.

Every error your declaration can produce

All of these are TileInvalid on your own tile record, and all are terminal: the tile is not bindable until you publish a version that fixes them. Everything from the third row down is prefixed with the entry label, so a real message reads `params` entry "count": `maxSize` is not a constraint Lexicon defines for `integer`.

A parameter whose type is unusable has its constraint checks skipped, because guessing which row to check against would report fields as misplaced that may be exactly right once the type is fixed.

Two of these only reach you if you write the record by hand: a constraint on the wrong type, and an unknown format. The tile builder in the Hub drops every constraint that no longer applies when you change a parameter's type, and it offers the eleven formats as a menu instead of a text field, so neither is reachable through it.

Declaring well

Fewer parameters, more clearly named. Every one you add is another decision somebody has to make before their page exists, and the fifth field is where people close the tab.

• Required only when genuinely required. A parameter is required when your tile cannot render anything sensible without it. If you can pick a reasonable value in code, make it optional, say so in the description, and default it.
• Name for the page, not for your code. heading and showReplies read well on a form. h1Text and flagB do not, and the name is a label the owner reads.
• Constrain, so the form helps. A maxGraphemes produces a counter. An enum produces a menu with no wrong answers in it. An accept on a blob stops somebody choosing a .mov for an avatar. A bare string produces a box with no guidance at all.
• Prefer a record parameter to five string parameters. If the thing you want is a profile, ask for app.bsky.actor.profile and let them pin the one they already have. Asking separately for a display name, a description, an avatar and a banner is four uploads of data they published years ago.
• Reserve maximum headroom. An integer bounded at a plausible number is better than an unbounded one, and better than one bounded so tightly that a reasonable use falls outside it.

Orbital Control has watched a great many people abandon a form at the fourth required field.

Related: Tiles for what a tile is and how binding pins a version, Building a tile for reading these values at runtime, Versions for what changing a declaration does to sites already bound, and Using a tile on your site for the other side of the form.
